5300
Light Duty Order Picker up to 6m
Toyota Material Handling
5300-OPC30
Order Pickers
The 5300 Order Picker truck is the ultimate in order picking value. A 2-stage or 3-stage mast can be spec'd to meet your application needs. With our ergonomic and intuitive controls and exclusive ACR system, you can count on years of performance with the 5300 Order Picker.
Key Benefits
- Precise Platform Movement for smooth and efficient picking
- Comprehensive Self-Diagnostics simplifies troubleshooting and service
- Auto-locking pallet clamp automatically locks and adjusts the pallet
Turning Radius (mm)
1829
Lift Height (mm)
6121
Load Capacity (kg)
1361
Travel Speed, no load (km/h)
10.46
Application & Usage
| Application Usage | Order Picking |
| Suitable Areas | Warehouses |
| Operator Position | Standing |
| Usage Intensity | Medium |
| Transport Distance | Medium |
Technical Specifications
| Length of Truck (mm) | 1880 |
| Width of Truck (mm) | 1016 |
| Turning Radius (mm) | 1829 |
| Overhead Guard Height (mm) | 2236 |
Lifting, Mast & Forks
| Fork Height (mm) | 83 |
| Fork Height, lowest (mm) | 82 |
| Free Lift (mm) | 559 |
| Lift Height (mm) | 6121 |
| Lift Speed, no load (m/s) | 0,15 |
| Mast Height, extended (mm) | 8280 |
| Mast Height, lowered (mm) | 2248 |
| Pick Height | N/A |
| Order Picking Stand height (in) | 245,5 |
| Order Picking Stand height (mm) | 6235 |
Capacity, Weight & Performance
| Load Capacity (kg) | 1361 |
| Load Center (mm) | 600 |
| Truck Weight, w/o battery (kg) | 2111 |
| Total Truck Height (mm) | N/A |
| Travel Speed, no load (km/h) | 10.46 |
| Tow Weight/Max Drawbar Pull (kg) | N/A |
Power Source
| Battery Voltage | 24 |
| Battery Capacity (Ah) | 1085 |
| Power Type | Lead acid |
| Transmission | N/A |
