BT Optio M-series
BT Optio 1T Narrow Man-Up
Toyota Material Handling
OME100N
Order Pickers
Are you looking for an efficient order picking solution for medium heights? Our medium-level BT Optio Order Picking Trucks have been designed for operations at a height of up to 3.4 metres. Optio trucks feature elevating forks, allowing easy placement of picked items onto the pallet or tray. The control panel can be easily switched from facing the forks to facing the mast.
Key Benefits
- Flexible man-up order picking truck for low to medium intense picking
- Equipped with an auxiliary lift that gives the operator the possibility to lift the load carrier to an ergonomic working position at all times
- Narrow chassis for picking up to 3.4 m picking height
- Fast acceleration and a high travel speed
- Smart truck: easy to connect, monitor & improve
Turning Radius (mm)
1590
Lift Height (mm)
2480
Load Capacity (kg)
1000
Travel Speed, no load (km/h)
12
Application & Usage
| Application Usage | Order Picking |
| Suitable Areas | Warehouses |
| Operator Position | Standing |
| Usage Intensity | Medium |
| Transport Distance | Medium |
Technical Specifications
| Length of Truck (mm) | 1740 |
| Width of Truck (mm) | 810 |
| Turning Radius (mm) | 1590 |
| Overhead Guard Height (mm) | 2450 |
Lifting, Mast & Forks
| Fork Height (mm) | 80 |
| Fork Height, lowest (mm) | 80 |
| Free Lift (mm) | N/A |
| Lift Height (mm) | 2480 |
| Lift Speed, no load (m/s) | 0,14 |
| Mast Height, extended (mm) | 4070 |
| Mast Height, lowered (mm) | 2450 |
| Pick Height | N/A |
| Order Picking Stand height (in) | 7 |
| Order Picking Stand height (mm) | 180 |
Capacity, Weight & Performance
| Load Capacity (kg) | 1000 |
| Load Center (mm) | 600 |
| Truck Weight, w/o battery (kg) | 1550 |
| Total Truck Height (mm) | 2450 |
| Travel Speed, no load (km/h) | 12 |
| Tow Weight/Max Drawbar Pull (kg) | N/A |
Power Source
| Battery Voltage | 24 |
| Battery Capacity (Ah) | 620 |
| Power Type | Lead acid |
| Transmission | N/A |
