Tracto W-Series
Tracto 1.2t
Toyota Material Handling
TWE120
Towing Tractor
Easy-to-use tow trucks with quick carrier connection, ideal for roll cages. The Tracto W-series is a pedestrian-operated towing solution that takes the strain out of moving loads.
Key Benefits
- Compact design and easy to use
- A variety of hooks allows connection to all common manual load carriers
- Easy access to confined spaces
- Easy operation on uneven floors
- Very ergonomic
Turning Radius (mm)
N/A
Lift Height (mm)
N/A
Load Capacity (kg)
1200
Travel Speed, no load (km/h)
5
Application & Usage
| Application Usage | Horizontal transport |
| Suitable Areas | Onboard vehicles; Outside adapted; Stores / Supermarkets |
| Operator Position | Walk With |
| Usage Intensity | Low-Medium |
| Transport Distance | Short-Medium |
Technical Specifications
| Length of Truck (mm) | 665 |
| Width of Truck (mm) | 493 |
| Turning Radius (mm) | N/A |
| Overhead Guard Height (mm) | N/A |
Lifting, Mast & Forks
| Fork Height (mm) | N/A |
| Fork Height, lowest (mm) | N/A |
| Free Lift (mm) | N/A |
| Lift Height (mm) | N/A |
| Lift Speed, no load (m/s) | N/A |
| Mast Height, extended (mm) | N/A |
| Mast Height, lowered (mm) | N/A |
Capacity, Weight & Performance
| Load Capacity (kg) | 1200 |
| Load Center (mm) | N/A |
| Tow Weight/Max Drawbar Pull (kg) | 1200 |
| Truck Weight, w/o battery (kg) | 90 |
| Total Truck Height (mm) | 1060 |
| Travel Speed, no load (km/h) | 5 |
Power Source
| Battery Voltage, en-US | 24 |
| Battery Capacity (Ah) | 22 |
| Power Type | Lead acid; Li-ion |
