BT Optio L-series
BT Optio 1.2T Stacking
Toyota Material Handling
OSE120CB
Order Pickers
The BT Optio L-series trucks ensure productivity by being powerful, efficient, adaptable, and easy-to-use. The OSE120CB is a low-level orderpicker with stacking possibilities.
Key Benefits
- Low-level picking with possibility to stack for increased flexibility
- Easy-to-use E-man for one-handed operation
- Fast acceleration and a high travel speed
- Can handle closed and open pallets
- Smart truck: easy to connect, monitor & improve
Turning Radius (mm)
1636
Lift Height (mm)
4150
Load Capacity (kg)
1200
Travel Speed, no load (km/h)
12
Application & Usage
| Application Usage | Order Picking |
| Suitable Areas | Warehouses |
| Operator Position | Standing |
| Usage Intensity | Medium |
| Transport Distance | Medium-Long |
Technical Specifications
| Length of Truck (mm) | 1703 |
| Width of Truck (mm) | 790 |
| Turning Radius (mm) | 1636 |
| Overhead Guard Height (mm) | 2226 |
Lifting, Mast & Forks
| Fork Height (mm) | 50 |
| Fork Height, lowest (mm) | 85 |
| Free Lift (mm) | 2121 |
| Lift Height (mm) | 4150 |
| Lift Speed, no load (m/s) | 0,27 |
| Mast Height, extended (mm) | 4720 |
| Mast Height, lowered (mm) | 1820 |
| Pick Height | N/A |
| Order Picking Stand height (in) | 5.3 |
| Order Picking Stand height (mm) | 135 |
Capacity, Weight & Performance
| Load Capacity (kg) | 1200 |
| Load Center (mm) | 500 |
| Truck Weight, w/o battery (kg) | 1599 |
| Total Truck Height (mm) | 2226 |
| Travel Speed, no load (km/h) | 12 |
| Tow Weight/Max Drawbar Pull (kg) | N/A |
Power Source
| Battery Voltage | 24 |
| Battery Capacity (Ah) | 620 |
| Power Type | Lead acid; Li-ion |
| Transmission | N/A |
