Toyota Material Handling

TSE 100/100W

Order Pickers

1000Kg Capacity

Featuring a low step-in design and a range of narrow chassis options, our tow tractors excel at towing multiple trolleys effortlessly. The truck's steering capability enables it to perform 360-degree turns, enhancing manoeuvrability even in tight spaces. Our TSE100 model is designed for conventional towing needs, while the TSE100W variant is specifically crafted to seamlessly dock with individual load carriers, streamlining order-picking operations. The latter version can also be paired with specialised equipment such as trolleys equipped with built-in ladders, facilitating efficient second-level picking tasks.

DOWNLOAD BROCHURE ENQUIRE
Dimensions+
Height, mast lowered h11550 mm
Lift movement1020 mm
Lift height1880 mm
Height, mast extended h42570 mm
Stand height h7180 mm
Additional lift780 mm
Stand height, elevated1200 mm
Height, fork lowered h1380 mm
Overall length l12840 mm
Length to face of forks l21690 mm
Fork dimensions s/e/l62/115/1150 mm
Ground clearance, centre of wheelbase70 mm
Turning radius Wa1540 mm
Clear width driver compartment entrance490 mm
Identification+
ManufacturerBT
ModelOSE100
DriveElectric
Operator typeStand on
Load capacity/rated load1000 kg
Load centre600 mm
Load distance, back of fork to wheel centre158 mm
Wheelbase1351 mm
Motor Information+
Drive motor rating S2 60 min2,8 kw
Lift motor rating S3 5%2,2 kw
Battery voltage, nominal capacity K524/465-620 v-ah
Battery weight, min./max475-530 kg
Energy consumption acc to VDI cycle kwh-h
Others+
Type of drive controlBT Powerdrive
Sound level at the driver’s ear according to EN 12 053
Performance data+
Travel speed, with/without load7,0/12,0 km-h
Lift speed, with/without load0,12/0,19 m-s
Lowering speed, with/without load0,33/0,36 m-s
Max. gradeability, with/without load9/13 82
Service brakeElectromagnetic
Weight+
Service weight without battery1294 kg
Axle load, with load, drive/support arm wheels550/1149 kg
Axle load, without load, drive/support arm wheels1113/365 kg
Wheels+
Drive / castor / fork wheelsVulkollan
Wheel size, front250 x 105 mm
Wheel size, rear140 x 80 mm
Additional wheels, dimensions mm
Wheels, number front / rear ( x =driven wheels)1x/2 mm
