| Tilt of fork, forward/backward | -2°/4° mm |
| Height, mast lowered h1 | 2887 mm |
| Free lift h2 | 2403 mm |
| Lift h3 | 6945 mm |
| Lift height | 7000 mm |
| Height, mast extended h4 | 7540 mm |
| Height of overhead guard (cabin) | 2198 mm |
| Seat height h7 | 1136 mm |
| Height of support arms | 268 mm |
| Height, fork lowered h13 | 55 mm |
| Overall length l1 | 2413 mm |
| Length to face of forks l2 | 1263 |
| Overall width b1 | 1270 mm |
| Fork dimensions s/e/l | 40/100/1150 * mm |
| Fork carriage ISO 2328, class/type A, B | 2A mm |
| Fork carriage width b3 | 819 mm |
| Width over forks b5 | 252 - 698 mm |
| Distance between wheel arms/loading surfaces | 900 * mm |
| Reach distance | 506 mm |
| Ground clearance, with load, below mast | 68 mm |
| Ground clearance, center of wheelbase m1 | 74 mm |
| Aisle width for pallets 1000x1200 crossways | 2687 mm |
| Aisle width for pallets 800x1200 lengthways | 2749 mm |
| Turning radius Wa | 1573 mm |
| Length across support arms l7 | 1744 mm |
| Manufacturer | BT |
| Model | RRE140H/HE |
| Drive | Electric |
| Type | Seated |
| Load capacity/rated load -- Q | 1400 kg |
| Load center - c | 600 mm |
| Load distance, centre of support arm wheel to face of forks | 310 mm |
| Wheelbase | 1311 mm |
| Drive motor rating S2 60 min | 7,5 kw |
| Lift motor rating S3 15% | 11,0 kw |
| Lift motor rating S3 15% (High speed version) | 15,0 kw |
| Battery voltage, nominal capacity K5 | 48/465 v-ah |
| Battery weight | 685 kg |
| Energy consumption according to VDI cycle | 3,4 kwh-h |
| Turnover output | 56 |
| Energy consumption at turnover output | 3,2 kwh-h |
| Type of drive control | Variable AC |
| Sound level at the driver’s ear according to EN 12 053 | 66 db-a |
| Travel speed, with/without load | 10,3/11 km-h |
| Travel speed, with/without load (High speed version) | 14/14 m-s |
| Lift speed, with/without load | 0,38/0,68 m-s |
| Lift speed, with/without load (High speed version) | 0,50/0,68 82 |
| Lowering speed, with/without load | 0,59/0,55 mm |
| Max. gradeability, with/without load | 10/15 82 |
| Acceleration time with/without load (over 10 m) | 5,4/4,9 s |
| Service brake | Electric |
| Service weight including battery | 3390 kg |
| Axle load, mast retracted without load, drive/support arm wheel | 2051/1339 kg |
| Axle load, mast extended with load, drive/support arm wheel | 651/4138 kg |
| Axle load, mast retracted with load, drive/support arm wheel | 651/4138 kg |
| Drive/support arm wheel | Vulkollan®/ |
| Wheel size, front | ø 350x140 mm |
| Wheel size, rear | ø 300x106 mm |
| Wheels, number front/rear (x=driven wheels) | 1x/2 mm |
| Track width, rear -- b11 | 1134 mm |
