| Overall height h15 | 1091 mm |
| Stand height h7 | 70 mm |
| Coupling height towing bar h10 | 270 mm |
| Overall length l1 | 1266 mm |
| Overall width b1/ b2 | 595/600 mm |
| Ground clearance, centre of wheelbase Ground clearance, centre of wheelbasez m2 | 33 mm |
| Turning radius Wa | 1085 mm |
| Clear width driver compartment entrance | 423 |
| Manufacturer | BT |
| Model | TSE100 - 702 |
| Drive | Electric |
| Operator type | Stand on |
| Load capacity/rated load -- Q | 1000 kg |
| Rated drawbar pull | 600 |
| Wheelbase | 815 mm |
| Drive motor rating S2 60 min | 1,0 |
| Battery voltage/nominal capacity K5 | 24/76, 105 |
| Battery weight | 58/75 |
| Energy consumption acc. to VDI cycle 3) | kwh-h |
| Type of drive control | Variable AC |
| Sound level at the driver's ear according to EN 12 053 | <70 db-a |
| Travel speed, with/without load | 9,0/12,0 km-h |
| Drawbar pull, with/without load | 600 |
| Max. drawbar pull, with/without load | 1320 |
| Gradeability, with/without load | 10/15 82 |
| Max. gradeability, with/without load 2) | 10/15 82 |
| Acceleration time, with/without load (0-10m) | 5,7/4,7 |
| Service brake | Electromagnetic |
| Service weight without battery | 250 kg |
| Axle load, with load, drive/castor/support arm wheel | 150/33/68 kg |
| Axle load, without load, drive/castor/support arm wheel | 150/33/68 kg |
| Drive/castor/fork wheel | Polyurethane/Polyurethane/Elastic |
| Wheel size, front | 150/33/68 |
| Wheel size, rear | 200 x 50 |
